Hikvision NVRs

Hikvision is the world’s leading supplier of video surveillance solutions. From its inception in 2001, Hikvision has played an active role in the ever-evolving video surveillance market, devoting eight percent of its annual revenue into research and development for continued product innovation. Featuring the industry’s strongest R&D workforce, Hikvision designs, develops, and manufactures innovative standard- and high-definition cameras, including a variety of Smart IP recorders and cameras with infrared, wide dynamic range, facial detection, object counting, and intrusion detection capabilities. Easily meeting all bandwidth and storage utilization requirements, Hikvision’s Smart IP Camera Series offers unparalleled image quality and customer convenience. Additionally, Hikvision’s Smart PTZ cameras incorporate proprietary image signal processing technology and use progressive scan sensors to deliver true color representation and clear images of fast-moving objects.

4K 8CH Plug & Play NVR (DS-7608NI-Q2/8P) 2TB


• Third-party network cameras supported
• Supports live view, storage, and playback of the connected camera at up to 8 MP resolution
• Connectable to smart IP cameras from Hikvision and the recording, playing back, and backing up of VCA alarms can be
realized
• VCA detection alarm is supported
• Hik-Connect for easy network management

4K 8CH Plug & Play NVR (DS-7608NI-Q2/8P) 4TB


• Third-party network cameras supported
• Supports live view, storage, and playback of the connected camera at up to 8 MP resolution
• Connectable to smart IP cameras from Hikvision and the recording, playing back, and backing up of VCA alarms can be
realized
• VCA detection alarm is supported
• Hik-Connect for easy network management

Hikvision 4K 8CH 8PoE Embedded Plug & Play NVR(DS-7608NI-I2/8P) 2TB


- Support H.265/H.264/MPEG4
- Up to 12 Megapixels resolution recording
- Support 1-ch HDMI, 1-ch VGA, HMDI at up to 4K
- Up to 80M incoming bandwidth
- Support 2 SATA interfaces
- 8 PoE, Plug & Play, Up to 12TB Storage

Hikvision 4K 8CH 8PoE Embedded Plug & Play NVR(DS-7608NI-I2/8P) 4TB


- Support H.265/H.264/MPEG4
- Up to 12 Megapixels resolution recording
- Support 1-ch HDMI, 1-ch VGA, HMDI at up to 4K
- Up to 80M incoming bandwidth
- Support 2 SATA interfaces
- 8 PoE, Plug & Play, Up to 12TB Storage

Hikvision 8 Channel NVR with 8-Port PoE, No HDD(DS-7608NI-E2/8P) 2TB


• Up to 6 Megapixel Resolution Recording
• 80 Mbps Incoming Bandwidth
• Supports H.264+ and H.264
• Synchronous HDMI and VGA Output 1920 × 1080p Resolution
• 8-ch Network Cameras Can Be Connected
• Up to 2 SATA Interfaces
• Plug & Play w/Up to 8 Independent PoE Network Connections
• Supports Network Detection, Including Network Delay, Packet Loss
• Alarm and Audio I/O

Hikvision 8 Channel NVR with 8-Port PoE, No HDD(DS-7608NI-E2/8P) 4TB


• Up to 6 Megapixel Resolution Recording
• 80 Mbps Incoming Bandwidth
• Supports H.264+ and H.264
• Synchronous HDMI and VGA Output 1920 × 1080p Resolution
• 8-ch Network Cameras Can Be Connected
• Up to 2 SATA Interfaces
• Plug & Play w/Up to 8 Independent PoE Network Connections
• Supports Network Detection, Including Network Delay, Packet Loss
• Alarm and Audio I/O

Hikvision 4 Channel NVR with 4-Port PoE, No HDD(DS-7604NI-E1/4P) 2TB


• Up to 6 Megapixel Resolution Recording
• 40 Mbps Incoming Bandwidth
• Supports H.264+ and H.264
• Synchronous HDMI and VGA Output 1920 × 1080p Resolution
• 4-ch Network Cameras Can Be Connected
• 1 SATA Interface
• Plug & Play w/Up to 4 Independent PoE Network Connections
• Supports Network Detection, Including Network Delay, Packet Loss
• Alarm and Audio I/O
• Supports network detection, including network delay, packet loss, etc

Hikvision 4 Channel NVR with 4-Port PoE, No HDD(DS-7604NI-E1/4P) 4TB


• Up to 6 Megapixel Resolution Recording
• 40 Mbps Incoming Bandwidth
• Supports H.264+ and H.264
• Synchronous HDMI and VGA Output 1920 × 1080p Resolution
• 4-ch Network Cameras Can Be Connected
• 1 SATA Interface
• Plug & Play w/Up to 4 Independent PoE Network Connections
• Supports Network Detection, Including Network Delay, Packet Loss
• Alarm and Audio I/O
• Supports network detection, including network delay, packet loss, etc

16 Channel H.265 12MP Hikvision Embedded Plug & Play Network Video Recorder(DS-7616NI-I2/16P) 2TB


• Up to 12 Megapixel Resolution Recording
• 160 Mbps Incoming Bandwidth
• 16 channels
• HDMI and VGA independent outputs provided
• HDMI video output up to 4K (3840*2160)
• Plug & Play w/Up to 16 Independent PoE Network Connections
• Alarm and Audio I/O

16 Channel H.265 12MP Hikvision Embedded Plug & Play Network Video Recorder(DS-7616NI-I2/16P) 4TB


• Up to 12 Megapixel Resolution Recording
• 160 Mbps Incoming Bandwidth
• 16 channels
• HDMI and VGA independent outputs provided
• HDMI video output up to 4K (3840*2160)
• Plug & Play w/Up to 16 Independent PoE Network Connections
• Alarm and Audio I/O

Hikvision AcuSense 4K UHD Network Video Recorder (DS-7616NXI-I2/16P/4S)


The DS-7616NXI-I2/16P/4S NVR features Hikvision’s new AcuSense technology. It includes a deep learning algorithm that accurately detects the presence of humans and vehicles. Also, the NVR recognizes standard human behaviors and automatically filters out routine alarms, which significantly increases VCA efficiency.
•HDMI Output Resolution Up to 4K (3840 x 2160)
•Up to 12 MP Full Channel Recording
•H.265+/H.265/H.264+/H.264/MPEG4 Video Compression
•Supports up to 8/16 IP Camera Connections
•8/16 Independent PoE Network Interfaces
•Human and Vehicle Detection, and Filtering of False VCA Alarms
•Smart Search and Smart Playback
•Line Crossing, and Region Entrance Detection

Hikvision 4k 16CH 16 PoE Embedded Plug and Play NVR (DS-7716NI-I4/16P)


The DS-7716NI-I4/16P NVR provides high resolution,high video compression, and HDMI video output up to 4K. 16 independent PoE connections offer easy setup, andsmart search and smart playback make locating specificincidents quick and accurate.
•Up to 12 MP Resolution
•16 IP Camera Inputs, 160 Mbps Bandwidth
•H.265+/H.265/H.264+/H.264/MPEG4 Compression
•HDMI Video Output Up to 4K (3840 × 2160)
•16 Independent PoE Network Interface Camera Connections
•Long Distance (100 to 300 m) Network Transmission via PoE
•Independent HDMI, VGA and CVBS Outputs
•4x (8 TB) SATA HDD, DVD-RW Option
•Smart Search and Smart Playback
•Alarm and Audio I/O

Hikvision 4k 32CH 16POE Embedded Plug and Play NVR (DS-7732NI-I4/16P)


The DS-7732NI-I4/16P NVR provides high resolution,high video compression, and HDMI video output up to4K.16 independent PoE connections offer easy setup, andsmart search and smart playback make locating specificincidents quick and accurate.
•12 MP Recording Resolution
•32 IP Camera Inputs (320 Mbps Total Inbound Bandwidth)
•H.265+/H.265/H.264+/H.264/MPEG4
•4K (3840 × 2160) HDMI Video Output
•Independent HDMI and VGA Outputs
•4 x SATA HDD Interfaces
•Smart Search and Smart Playback
•Alarm and Audio I/O
•Long Distance (100 to 300 m) Network Transmission via PoE
•16 PoE ports

Hikvision 4k 32CH Embedded Plug and Play NVR (DS-7732NI-I4)


The DS-7732NI-I4 NVR provides high resolution, high video compression, and HDMI video output up to 4K. The DS-7732NI-I4 offers easy setup. The model includes smart search and smart playback to make locating specific incidents quick and accurate.
•32 IP Camera Inputs @ 256 Mbps
•.265+/H.265/H.264+/H.264/MPEG4
•4K (3840 × 2160) HDMI Video Output
•4x SATA HDD, DVD-RW Option
•Smart Search and Smart Playback

Hikvision 16CH 16PoE Embedded Plug and Play NVR No HDD (DS-7716NI-SP/16)


The DS-7716NI-SP/16 NVR provides high resolution, high video compression, and HDMI video output. 16 independent PoE connections offer easy setup, and smart search and smart playback make locating specificincidents quick and accurate.
•Up to 6 Megapixel Live and Playback Resolution
•16 IP Camera Inputs, 100 Mbs Bandwidth
•Supports H.264+ and H.264
•Independent HDMI and VGA Outputs
•1920 x 1080 Resolution
•Plug and Play with 16 Independent PoE Connections
•4x SATA HDD, 6 TB Capacity, DVD-RW Option
•Alarm and Audio I/O

Seagate SkyHawk 1TB (ST1000VX005-SKYHAWK)

Seagate SkyHawk 1TB (ST1000VX005-SKYHAWK)

• 1 TB
• 3.5 Inch Form Factor

Seagate SkyHawk 2TB (ST2000VX008-SKYHAWK)


• 2 TB
• 3.5 Inch Form Factor

Seagate SkyHawk 3TB (ST3000VX010-SKYHAW)


• 3 TB
• 3.5 Inch Form Factor

Seagate SkyHawk 4TB (ST3000VX007-SKYHAWK)


• 4 TB
• 3.5 Inch Form Factor

Seagate SkyHawk 6TB ST6000VX0023-SKYHAWK


• 6 TB
• 3.5 Inch Form Factor

Seagate SkyHawk 8TB (ST8000VX004-SKYHAWK)


• 8 TB
• 3.5 Inch Form Factor

Seagate SkyHawk 10TB (ST10000VX004-SKYHAWK)


• 10 TB
• 3.5 Inch Form Factor
